STUDY ON RESERVOIR MICRO-CHARACTERISTIC OF CLASTIC ROCKS IN CHANGLING FAULTED DEPRESSION OF THE SONGLIAO BASIN
-
摘要: 在对长岭断陷层碎屑岩储层宏观沉积特征研究的基础上,通过岩心观察,结合测井资料、岩石薄片、铸体薄片、扫描电镜、物性、孔隙结构等分析化验资料研究表明:断陷层碎屑岩储层的岩石学类型主要为长石岩屑砂岩、长石砂岩、岩屑长石砂岩;储集空间类型主要为裂缝—孔隙型;储层物性差,主要为低孔低渗和特低孔特低渗储层;储层具有排驱压力及饱和度中值压力较高、孔喉半径小、孔隙结构参数总体较差的特征;强烈的压实—压溶作用是形成低孔低渗的主要原因之一;成岩阶段划分认为东岭地区断陷层主要处于晚成岩期的A阶段,腰英台地区断陷层(主要指登娄库组、营城组)主要处于晚成岩期的B、C阶段。通过以上分析并结合碎屑岩储层评价标准认为:长岭断陷层碎屑岩储层主要为Ⅲ类或Ⅲ—Ⅳ类储层;有利区主要发育于东岭和双深1井等地区,其次为腰英台地区。Abstract: Based on macro-sedimentary characteristics of clastic rocks and observed by cored samples,several analysis methods such as logging data,rock thin section,casting slice,scanning electron microscope,physical properties and pore structure are used to study the clastic reservoir in Changling Faulted Depression.The result showed that the petrologic types of reservoir in the Changling Faulted Depression mainly include feldspathic lithic sandstone,feldspar sandstone and debris feldspar sandstone.The reservoirs are mainly fractured-porous reservoirs.The physical properties of clastic rocks reservoir is low porosity and permeability or extra low porosity and permeability.The reservoir in this area is characterized by higher drainage capillary pressure and saturation medium pressure value,small pore throat radium and worse pore texture parameters.The stronger compaction-pressolution is the main reasons for the formation of low porosity and permeability.According to the diagenesis stage division,the faulted depression in Dongling area is regarded as A stage of late diagenesis.However,the faulted depression in Yaoyingtai area is grouped into B and C stage of late diagenesis.Combined with evaluation standard of clastic rocks,it was generally considered that the calstic rocks reservoir in Changling Faulted Depression is regarded as Ⅲ or Ⅲ-Ⅳ,and the favorable exploration area is mainly developed in Dongling and Shuangshen Well 1 area,then in Yaoyingtai area.
-
[1] 杨铭辉,郭力,赵洪涛等.松辽盆地南部东南隆起区储层特征[J].石油实验地质,2006,28(4):330-334 [2] 龙胜祥,王果寿,陈振林等.含油气盆地分析与资源评价——以松辽盆地十屋-德惠地区为例[M].北京:地质出版社,1992 [3] 刘成林,朱筱敏,曾庆猛.苏里格气田储层成岩序列与孔隙演化[J].天然气工业,2005,25(11):1-4 [4] 袁静,王乾泽.东营凹陷下第三系深部碎屑岩储层次生孔隙垂向分布及成因分析[J].矿物岩石,2001,21(1):43-47 [5] 姜向强,钟大康,张琼.辽东湾地区古近系砂岩成岩作用与孔隙演化[J].西安石油大学报,2007,22(6):14-19 [6] 王恕一,蒋小琼,管宏林等.川东北地区普光气田飞仙关组储层孔隙演化[J].石油实验地质,2009,31(1):26-30 [7] 刘伟新,承秋泉,王延斌等.油气储层特征微观分析技术及其应用[J].石油实验地质,2006,28(5):489-492 [8] 王成,邵红梅,洪淑新等.松辽盆地北部深层碎屑岩储层物性下限及与微观特征的关系[J].大庆石油地质与开发,2007,26(5):18-24 [9] 罗月明,刘伟新,谭学群等.鄂尔多斯大牛地气田上古生界储层成岩作用评价[J].石油实验地质,2007,29(4):384-390 [10] 路慎强.渤海湾盆地东营凹陷古近系碎屑岩储层成岩研究[J].石油实验地质,2008,30(5):456-459 [11] 王宝清.川西-川西北地区上三叠统碎屑储集岩成岩作用[J].石油实验地质,2008,30(1):69-81 [12] 穆曙光,张以明.成岩作用及阶段对碎屑岩储层孔隙演化的控制[J].西南石油学院学报,1994,16(3):22-27 [13] 焦玉国,李景坤,乔建华等.伊利石结晶度指数在岩石变质程度研究中的应用[J].大庆石油地质与开发,2005,24(1):41-44 [14] 朱莉,朱敏.合肥盆地中生界地层的热演化程度——伊利石结晶度的指示[J].安徽地质,2006,16(3):169-176 -
